Wave from Helix (Slinky)

Simple type model, it comprises a wooden board 700 x 90 mm (L x W) on four feet, fitted with two steel wires about 0.3mm x 1m (dia x length). At one end of base there are two 50 N spring balances with hooks and at the other end are two wrest pins, supplied complete with three bridges, one large, to span both wires and two small bridges for individual wires, two steel wires 0.3 mm dia. x 1 meter long.

The apparatus consists of a wooden framed tray with a plate glass base and detachable legs, overall size of tray 600x 520x 56mm deep.

A pair of support rods with integral ‘G’ clamps is provided which can be attached to the sides of the tank and used to carry the wave generating system. A set of 4 metal barriers (reflectors) is included consisting of a pair of straight barriers 150 x 25mm, a curved barrier of 215 mm. chord length x 25mm high and a short, straight barrier 25 x 25mm, to minimize unwanted reflections from the sides of the tank a set of four loose gauze strips are provided which, when is use, are arranged around the edges to from a ‘beach’ on all sides.
