Stroboscope Hand

The apparatus consists of a framed tray with a plexi glass base and detachable legs, overall size of tray 600 x 520 x 56 mm deep. A pair of support rods with integral ‘G’ clamps is provided which can be attached to the sides of the tank and used to carry the wave generating system. A set of 4 metal barriers (reflectors) is included consisting of a pair of straight barriers 150 x 25 mm, a curved barrier of 215mm chord length x 25mm high and a short, straight barrier of 25 x 25 mm.

It comprises two aluminium tubes telescoping into each other, so that the column of air within the tubes may be altered from 30 cms to 53 cms, outer tube fits into a wooden base.
