Meter – Dual Scale Voltmeter

A simple demonstration of a Dynamo Model mounted on a wooden base. Hand driven by a gear. Simplified open frame construction which can be readily understood without detriments to its essential similarity to real machine. A 2 pole armature wound by enamelled copper wire to rotate in U shape magnet in pivot. While in rotation process through the gear wheel by hand, the bulb provided glows.
